Shunli Custom Professional Manufacturer Hair Dryer and Micro Vacuum Cleaner 390PH 12v Dc Motor Brush Brushless
Product Description
Professional Manufacturer Hair Dryer and Micro Vacuum Cleaner 390PH 12V DC Motor
📋
Product Description
Product Details
Motor Customized Specification Available
📐
Reference Drawings
RS - 365
RS - 385
RS - 395
The length of shaft can be customized.
📊
Reference Datasheet
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-390SH | 20156R | 6.0~12.0 | 12VDC | 5000 | 0.08 | 4243 | 0.33 | 6.07/61.9 | 2.72 | 2.22 | 42.2/430 |
| 2975 | 6.0~12.0 | 12VDC | 12000 | 0.29 | 10165 | 0.33 | 5.75/58.6 | 1.31 | 8.9 | 80.4/820 | |
| RS-395SH | 15130 | 6.0~12.0 | 12VDC | 3650 | 0.66 | 2949 | 0.25 | 5.83/59.5 | 1.8 | 1.06 | 30.4/310 |
| 15100R | 6.0~24.0 | 24VDC | 10300 | 0.07 | 8893 | 0.38 | 7.09/72.3 | 6.68 | 2.66 | 54.9/560 | |
🌟
Recommend Products
✉️
Feedback
Looking forward to your feedback!
Frequently Asked Questions (FAQ)
1. What are the primary applications for the 390PH DC motor?
The 390PH series is professionally designed for high-performance hair dryers and micro vacuum cleaners, providing reliable power and efficient operation.
2. Can the motor technical specifications be customized?
Yes, we offer customization for motor specifications, including voltage, speed, and torque, to meet your specific product requirements.
3. Is it possible to customize the motor shaft?
Absolutely. The length and shape of the shaft can be customized according to your mechanical design needs.
4. What is the typical operating voltage range for these motors?
Our PMDC motors typically operate within a range of 6.0V to 24.0V DC, depending on the specific model and winding configuration.
5. What speeds can the RS-390SH model reach?
The RS-390SH model can achieve various speeds depending on the configuration, with some versions reaching up to 12,000 RPM at no-load.
6. Are these motors suitable for professional-grade appliances?
Yes, as a professional manufacturer, our motors are engineered for durability and performance suitable for both consumer and professional-grade hair dryers and cleaning equipment.
