Shunli RS-380 RS-385 Micro 380 DC Motor 12V~24V 13000RPM High Speed Large Torque for Electric Drill Garden Tools Toy Model
Product Description
RS-380 RS-385 Micro 380 DC Motor 12V~24V 13000RPM High Speed Large Torque for Electric Drill Garden Tools Toy Model
Product Details
Motor Customized Specification, Please contact me.
Reference Drawing
RS - 365
RS - 385
RS - 395
The length of shaft can be customized, Please contact me.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-390SH | 20156R | 6.0~12.0 | 12VDC | 5000 | 0.08 | 4243 | 0.33 | 6.07 / 61.9 | 2.72 | 2.22 | 42.2 / 430 |
| 2975 | 6.0~12.0 | 12VDC | 12000 | 0.29 | 10165 | 0.33 | 5.75 / 58.6 | 1.31 | 8.9 | 80.4 / 820 | |
| RS-395SH | 15130 | 6.0~12.0 | 12VDC | 3650 | 0.66 | 2949 | 0.25 | 5.83 / 59.5 | 1.8 | 1.06 | 30.4 / 310 |
| 15100R | 6.0~24.0 | 24VDC | 10300 | 0.07 | 8893 | 0.38 | 7.09 / 72.3 | 6.68 | 2.66 | 54.9 / 560 | |
Looking forward to your feedback!
Frequently Asked Questions
Q1: What is the operating voltage range for these micro DC motors?
A1: These motors generally operate within a range of 6.0V to 24.0V DC depending on the specific model, allowing them to support different power requirements.
Q2: Can the motor shaft be customized?
A2: Yes, the length and design of the motor shaft can be customized according to your exact mechanical specifications.
Q3: What are the primary applications of the RS-380 and RS-385 DC motors?
A3: They are widely used in high-speed, high-torque applications such as electric drills, garden tools, vacuum cleaners, and various DIY toy models.
Q4: How do I request customized specifications for my project?
A4: You can request adjustments in rated voltage, operating speed, torque, and power. Please share your project parameters to receive customized specifications.
Q5: Do these motors support high-speed operation?
A5: Yes, these PMDC motors can achieve high speeds ranging from 5,000 RPM up to 13,000 RPM under nominal voltage conditions, ensuring high efficiency.
