SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W
Product Description
⚙️ Product Description
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (mN.m / gf.cm) | Power (W) | Current (mA) | Torque (mN.m / gf.cm) | ||
| RF-370CA | 061700 | 6.0~24.0 | 24 VDC | 1320 | 3 | 1000 | 8 | 0.98/10 | 0.1 | 260 | 4.02/41 |
| RC-370CH | 20123 | 3.0~6.0 | 6 VDC | 8000 | 70 | 6878 | 420 | 2.4/24.5 | 1.71 | 2550 | 17/173 |
| RC-370SH | 4730 | 3.0~5.0 | 4.5 VDC | 17500 | 550 | 15199 | 3630 | 7.2/73.4 | 11.51 | 24000 | 55/561 |
| 18139 | 6.0~12.0 | 12 VDC | 10000 | 130 | 8439 | 700 | 5.8/59.2 | 5.17 | 3800 | 37.5/382.5 | |
💡 Click on the tilt font to know more parameters!
📊 Application
❓ Frequently Asked Questions
1. What is the operating voltage range for the RC-370SH (4730) motor?
The operating voltage range for this model is 3.0V to 5.0V, with a nominal rated voltage of 4.5V DC.
2. What are the no-load speed and no-load current specifications for the 4.5V model?
At no-load condition, the motor delivers a speed of 17,500 RPM with a low current draw of 550 mA.
3. What is the maximum power output of the RC-370SH-4730 motor?
The motor offers a high efficiency output power of 11.51W under nominal loaded conditions.
4. What is the stall torque and stall current of this PMDC motor?
The stall torque reaches up to 55 mN.m (or 561 gf.cm) with a stall current of 24,000 mA (24A).
5. Can this motor operate at other voltages like 12V?
Yes, within the RC-370SH series, there is also the 18139 model designed to run on a nominal 12V DC with an operating range of 6.0V to 12.0V.
